HP USB-C Elite Display Docking Station

Ports Configuration

• 1 × USB‑C host cable (connects to laptop)

• 1 × HDMI output

• 1 × DisplayPort output

• 1 × USB‑C downstream (data/power to peripherals)

• 2 × USB‑A 3.0 ports

• 2 × USB‑A 2.0 ports

• 1 × RJ‑45 Gigabit Ethernet

• 1 × 3.5 mm combo audio jack (headset mic & headphones)

Power & Functionality

• Bus-powered via AC adapter (65 W)

• Plug-and-play with DisplayLink drivers

• No laptop charging via the dock (cannot power host)

Display Support

• Daisy-chain or extend two monitors: HDMI + DisplayPort

• Up to 1080p @ 60 Hz, sometimes 2K depending on host support

Data & Speed

• USB‑A 3.0 ports: up to 5 Gbps

• USB‑A 2.0 ports: basic peripheral speeds

Design & Compatibility

• Compact and travel-friendly

• Passive cooling

• Compatible with USB-C DisplayPort Alt Mode laptops

• Works best on Windows systems, basic support on macOS/Linux
